MRCOOL DIY Easy Pro 9K BTU Ductless Mini Split Heat Pump Complete System, EZPRO-09-HP-11516
$1,252.00
MrCool DIY Easy Pro 9k BTU Ductless Mini-Split Heat Pump System
- Fast, Free Shipping
- 30-Day Money-back Guarantee
- Payment Methods
Introducing one of the most straightforward and cost-effective HVAC solutions available from MRCOOL: the MRCOOL DIY Easy Pro 9K BTU Ductless Mini Split Heat Pump Complete System.
Designed for effortless installation, this system is capable of heating or cooling areas ranging from 175 to 350 square feet with an impressive 20 SEER efficiency rating. It includes a 16-foot pre-charged line set equipped with Fast Connection fittings for streamlined setup. Among its advanced features is the Follow Me functionality, which ensures consistent comfort wherever you are in the room. You can also take advantage of multiple operational modes like Sleep, Auto, and Timer to customize your comfort experience. Maintenance is straightforward—air filters are easily rinsed and replaced, and both indoor and outdoor units can be cleaned with a damp or dry cloth.
Control the system with the provided remote, the SmartHVAC app, or through your Amazon Alexa or Google Assistant for seamless integration into your smart home setup. Benefit from long-term peace of mind with the 1-year compressor warranty and 2-year parts warranty. This energy-efficient system is not only packed with features but also simple to install and maintain, offering the ultimate in home comfort.
Key Features:
- Up to 20 SEER efficiency
- Gold Fin condenser: corrosion-resistant, perfect for coastal areas
- Energy-efficient DC inverter
- Low ambient cooling: operates in exterior temperatures as low as 5°F, ideal for server rooms, greenhouses, and year-round cooling needs
- Additional features include timer mode and refrigerant leakage detection
- Includes SmartHVAC WiFi Control Module for improved setup and enhanced functionality for Apple and Android devices; compatible with Amazon Alexa and Google Assistant
| 5 star | 0% | |
| 4 star | 0% | |
| 3 star | 0% | |
| 2 star | 0% | |
| 1 star | 0% |
Our best Products
-
Product Overview
  Covers 350 sq. ft.    Â
 DIY Installation
  Wall Mounted      Â
  Number of Zones: 1
  Voltage: 110 to 120
-
Specifications and Dimensions
Condenser Dimensions 28.35″W x 10.63″D x 19.49″H Condenser Weight 54.45 lbs Air Handler Dimensions 28.7″W x 7.87″D x 11.5″H Air Handler Weight 17.64 lbs SEER 20 EER 11.5 COP 47 3.14 HSPF hspf4/hspf5 : 10.3/8.5 CFM 238.82 / 170.00 / 137.06 Cooling Capacity 9,000 BTU Heating Capacity 10,000 BTU Voltage Requires a minimum of 115V/60HZ/20-30A (please check your home meets this electrical requirement prior to purchase) Phase 1 Cycle 60 Hz Max Fuse Breaker 30 A Min Circuit Ampacity 20 A Color White Rate Load 14.5 A Max Coverage Area 175 to 350 sqft Zone Capacity 1 Refrigerant Type R-410A Refrigerant Volume 24.69 oz Decibel Rating 22.5 dBA to 38.5 dBA Decibel Rating Low 22.5 dBA Decibel Rating High 38.5 dBA Inverter Yes Min Ambient Cool 5F – 122F Min Ambient Heat 5F – 75.2F Line Set Length 16ft – Included Max Lineset Length 82ft Liquid Line Size 1/4 in Suction Line Size 1/2 in Compressor Motor Type Rotary Condenser Fan Motor RPM 850/500 Blower Motor Speeds 3 Blower Motor RPM 1050/810/690 Filter Type Washable Modes Fan Only
Sleep Mode
Auto
Cool
Dry
HeatWifi Compatibility Yes App Compatibility Yes Compatible with iOS
AndroidIncludes Remote
BatteriesCertifications UL Listed
Energy Star
AHRIRegistered Warranty 2-year Parts/1-year Compressor -
Coverage Area
For optimal cooling or heating, refer to our coverage chart to determine the appropriate BTU capacity based on the square footage of your space:
- Square Feet: 180-375 | BTU = 9K
- Square Feet: 376-500 | BTU = 12K
- Square Feet: 501-750 | BTU = 18K
- Square Feet: 751-1,000 | BTU = 24K
- Square Feet: 1,001-1,500 | BTU = 36K
Keep in mind that additional factors such as insulation, ceiling height, and the presence of appliances may impact performance. For personalized assistance, feel free to reach out to our Sales Team.
-
-
Handling Line Sets
When installing your MRCOOL system, handle refrigerant lines carefully to ensure optimal performance and prevent damage.
Bending the Copper Lines: Maintain a minimum 4-inch bend radius and use smooth curves instead of sharp angles to protect the lines and ensure proper refrigerant flow.
Avoid Repeated Bending: Bending copper lines more than three times can harden and weaken them, increasing the risk of breakage. Handle with care and minimize adjustments.
For best results, use gradual bends and consult a licensed professional or our support team if needed.
